Standard Features:

• Thermal Transfer or Direct Thermal print method
• ZPL and EPL programming languages
• Single LED status indicator
• Single button for feed/pause
• USB connectivity
• OpenACCESS™ for easy media loading
• Dual-wall frame construction
• ENERGY STAR qualified

Physical Characteristics:

• Thermal Transfer:
10.5 in. L x 7.75 in. W x 7.5 in. H
267 mm L x 197 mm W x 191 mm H
• Direct Thermal:
8.6 in. L x 6.9 in. W x 5.9 in. H
220 mm L x 176 mm W x 151 mm H
• Weight: 2.5 lbs./1.1 kg

Printer Specifications:

• Resolution: 203 dpi/8 dots per mm
• Memory: 256 MB Flash; 128 MB SDRAM
• Maximum Print Width: 4.09 in./104 mm
• Maximum Print Speed: 4 in./102 mm per second
• Media Sensors: Movable black mark sensor, limited range from center to left side / Fixed off-center gap sensor
• Firmware: ZPL II; EPL 2; XML

Media and Ribbon Characteristics:

• Maximum Label Length: 39.0 in./991 mm
• Media Width: 1.00 in./25.4 mm to 4.4 in./112 mm
• Media Roll Size: 5.00 in./127 mm outer diameter
• Core inner diameter: 0.5 in. (12.7 mm) and 1.0 in. (25.4 mm) standard, 1.5 in. (38.1), 2.0 in., (50.8 mm) and 3.0 in. (76.2 mm) using optional adapters
• Thickness: 0.003 in. (0.08 mm) min.; 0.0075 in. (.1905 mm) max. (tear-off mode only)
• Media Types: Roll-fed or fan-fold, die cut or continuous with or without black mark, tag stock, continuous receipt paper, and wristbands
• Ribbon Outside Diameter: 1.34 in./34 mm (74 m)
• Maximum Ribbon Length: 244 ft. (74 m)
• Ribbon Ratio: 1:1 media to ribbon (74 m)
• Ribbon Width: 1.33 in./33.8 mm ~ 4.3 in./109.2 mm
• Ribbon Core I.D.: 74 Meter ribbon 0.5 in./12.7 mm

Operating Characteristics:

• Operating Temp: 40° to 105° F/4.4° to 41° C
• Storage Temp: -40° to 140° F/-40° to 60° C
• Operating Humidity: 10% to 90% non-condensing
• Storage Humidity: 5% to 95% non-condensing
• Electrical: Auto-detectable (PFC Compliant) 100-240VAC, 50-60Hz; ENERGY STAR qualified

Operations and Accessories:

• Media Handling: Factory installed peeler
• Real Time Clock: None

Fonts/Graphics/Symbologies:

• Bar Code Ratios: 2:1 and 3:1
• 1D Bar Codes: Code 11, Code 39, Code 93, Code 128, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2-or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar and Planet Code
• 2D Bar Codes: Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, MicroPDF, Aztec
• Fonts and Graphics: 16 resident expandable ZPL II bitmap fonts
Two resident scalable ZPL fonts
Five resident expandable EPL2 fonts
Native open-type font support
Unicode compliant for multi-language, on demand thermal printing
China units include SimSun simplified Chinese font
50 MB user available non-volatile memory, 8 MB user available SDRAM
