| CAPACITY | 1843.2 TB with SFF expansion / 2344.32 TB with LFF expansion (with maximum expansion) |
|---|---|
| FORM FACTOR | 2U |
| STORAGE EXPANSION OPTIONS | 24 drive bay 2060 SFF drive enclosure and/or 12 drive bay 2060 LFF drive enclosure (add up to 9) |
| SYSTEMS INSIGHT MANAGER SUPPORT | No |
| STORAGE MIRRORING SUPPORT | No |
| SAN BACKUP SUPPORT | Yes |
| CLUSTERING SUPPORT | Yes |
| HOST INTERFACE | 8-ports 16Gb FC, 4 ports per controller |
| DRIVE DESCRIPTION | Up to 24 SFF HDD and/or SSD per array model |
| STORAGE CONTROLLER | (2) HPE MSA 2060 16Gb FC storage controllers, 4-ports each |
| COMPATIBLE OPERATING SYSTEMS | Windows Server 2022 Windows Server 2019 Windows Server 2016 VMWare vSphere 6.7 Red Hat Linux 8 SuSE SLES 15 |
| WARRANTY | Three-year limited warranty, parts exchange next business day delivery. Disk enclosures, hard drives and Options for the HPE MSA 2060 carry their own warranty. |
| PRODUCT DIMENSIONS (METRIC) | 8.9 x 44.5 x 50.8 cm |
| WEIGHT | 5 kg |
