CPU Specifications
- Total Cores 8
- Total Threads 16
- Max Turbo Frequency 3.70 GHz
- Processor Base Frequency 3.00 GHz
- Cache 11 MB
- Max # of UPI Links 2
- TDP 115 W
Memory Specifications
- Max Memory Size (dependent on memory type) 1 TB
- Memory Types DDR4-2667
- Maximum Memory Speed 2667 MHz
- Max # of Memory Channels 6
- Intel® Optane™ Persistent Memory Supported Yes
- ECC Memory Supported ‡ Yes
Expansion Options
- Scalability 4S
- PCI Express Revision 3.0
- Max # of PCI Express Lanes 48
Package Specifications
- Sockets Supported FCLGA3647
- TCASE 79°C
- Package Size 76.0mm x 56.5mm
Advanced Technologies
- Intel® Deep Learning Boost (Intel® DL Boost) Yes
- Intel® Speed Select Technology – Performance Profile No
- Intel® Speed Select Technology – Base Frequency No
- Intel® Resource Director Technology (Intel® RDT) Yes
- Intel® Speed Shift Technology Yes
- Intel® Turbo Boost Max Technology 3.0 No
- Intel® Turbo Boost Technology 2.0
- Intel® Hyper-Threading Technology Yes
- Intel® Transactional Synchronization Extensions Yes
- Intel® 64 Yes
- Instruction Set Extensions Intel® SSE4.2, Intel® AVX, Intel® AVX2, Intel® AVX-512
- # of AVX-512 FMA Units 1
- Enhanced Intel SpeedStep® Technology Yes
- Intel® Volume Management Device (VMD) Yes
Security & Reliability
- Intel vPro® Platform Eligibility Yes
- Intel® AES New Instructions Yes
- Intel® Trusted Execution Technology Yes
- Execute Disable Bit Yes
- Intel® Run Sure Technology Yes
- Mode-based Execute Control (MBEC) Yes
- Intel® Virtualization Technology (VT-x) Yes
- Intel® Virtualization Technology for Directed I/O (VT-d) Yes
- Intel® VT-x with Extended Page Tables (EPT) Yes
